Dynamic Temperature Control System

SUNDI (-60 ~ 250℃)

  • Temperature Range-60 ~ 250℃
  • Temperature Control Accuracy±0.5℃
  • Heating Power2.5KW ~ 60KW
  • Cooling Capacity AT 20℃2.5KW ~ 60KW
  • Circulating Pump Flow and Pressure20~250L/min 2~2.5BAR
  • Power Supply5 ~ 95KW
  • Place of OriginChina
  • Quality Guarantee Period12 months

Product Details

FEATURES:

Typical Applications Of Cooling Heating Chiller: dynamic constant temperature control of high pressure reactor cold and heat source, dynamic constant temperature control of double-layer glass reactor cold and heat source, dynamic constant temperature control of double-layer reactor cold and heat source, constant temperature of microchannel reactor Control; small thermostat control system, steaming system temperature control, material low temperature high temperature aging test, combined chemical cold source heat source constant temperature control, semiconductor equipment cooling heating, vacuum chamber cooling heating constant temperature control.

Dynamic Temperature Control System Advantages And Functions: temperature range from -120℃ to 350℃, superior performance, high precision, intelligent temperature control. Multi-function alarm system and safety function, 7-inch, 10-inch color TFT touch screen graphic display, magnetic drive pump, no shaft seal leakage problem.

Ultra-high Temperature Cooling Technology Can Directly Cool Down From 300 High Temperature. Because only the heat transfer medium in the expansion chamber is in contact with the oxygen in the air (and the temperature of the expansion tank is between normal temperature and 60℃), which can reduce the heat transfer medium. The risk of oxidizing and absorbing moisture from the air. No high-temperature heat medium evaporates at high temperature, and continuous control can be achieved with -80℃ to 190℃, -70℃ to 220℃, -88℃to 170℃, -55℃ to 250℃, and -30℃ to 300℃ without pressurization temperature.

Model SUNDI
-625
SUNDI
-625W
SUNDI
-635
SUNDI
-635W
SUNDI
-655
SUNDI
-655W
SUNDI
-675
SUNDI
-675W
SUNDI
-6A10
SUNDI
-6A10W
SUNDI
-6A15W
SUNDI
-6A25W
SUNDI
-6A38W
SUNDI
-6A60W
SUNDI
-6A95W
SUNDI
-6A130W
SUNDI
-6A200W
Temp. range -60℃~+250℃
Control Mode Feedback PID + Our special dynamic control calculation, PLC controller
Temp. control process temp. control and jacket temp. control model
Temp. difference Set or control the temperature difference between jacket oil and raw material process
Program Editor 10 programs, each program can edit 42 steps.
Communication
Portocol
MODBUS RTU Protocol,RS485 interface
Material temp.
feedback
PT100 OR 4~20mA or communication(normal: PT100)
Temp. feedback The temp. of three points: the inlet and outlet of equipment, reactor material temp.(external temp. sensor)
Medium temp.
acccuracy
±0.5℃ ±1℃
Material temp.
accuracy
±1℃ ±1.5℃
Heating power kW 2.5 3.5 5.5 7.5 10 15 25 38 60 95 130 200
Cooling
capacity
kW at
250℃ 2.5 3.5 5.5 7.5 10 15 25 38 60 95 130 200
100℃ 2.5 3.5 5.5 7.5 10 15 25 38 60 95 130 200
20℃ 2.5 3.5 5.5 7.5 10 15 25 38 60 95 130 200
-20℃ 2 3 4.8 6 8.2 12 25 38 56 80 90 150
-40℃ 0.95 1.45 2.3 3.1 4.8 7.8 18 23 31 45 56 93
-55℃ 0.25 0.5 0.75 0.9 1.5 2.8 6 8 11 16 20 32
Circulation pump
max L/min bar
20 35 50 50 110 110 150 200 250 400 400 600
2 2 2 2 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5
pump LNEYA magnetic drive pump German magnetic drive pump
Compressor Tecumseh closed compressor Dorin semi-closed compressor
Expansion valve Emerson thermal expansion valve/Emerson electronic expansion valve/danfoss thermal expansion valve.
Evaporator DANFOSS/KAORI Plate heat exchanger
Operation Panel 7-inch touch screen,show temp curve\EXCEL data output
Safety protection Self-diagnosis function; freezer overload protection; high pressure switch, overload relay,thermal protection device, liquid low level
protection, high temperature protection and temperature fault protection.
Closed circulation
system
The whole system is full closed circulation, there is no oil mist at high temperature and no water vapor at low temperature, pressure
do not rise up when system is running. The system will supply oil automatically at low temperature.
Refrigerant R404A/R23 mixture,optional: R125/R23 mixture
Connection size G1/2 G3/4 G3/4 G1 G1 G1 DN32 DN40 DN40 DN50 DN65 DN65
Water-cooled type
W(@20℃)
900
L/H
1200
L/H
1800
L/H
2100
L/H
3000
L/H
4000
L/H
8.5
m³/H
14
m³/H
20
m³/H
29
m³/H
38
m³/H
47
m³/H
Dimension cm 50
*85
*130
55
*68
*145
55
*68
*145
70
*100
*175
80
*120
*185
100
*95
*185
150
*100
*185
/ / / / /
Isolate size cm 45
*85
*130
45
*85
*130
55
*95
*170
55
*95
*170
70
*100
*175
80
*120
*185
100
*150
*185
205
*145
*205
205
*145
*205
245
*145
*225
300
*160
*225
400
*160
*225
Positive pressure cm 45
*110
*130
55
*120
*170
55
*120
*170
70
*125
*175
80
*145
*185
80
*145
*185
100
*175
*185
205
*145
*205
205
*145
*205
245
*145
*225
300
*160
*225
400
*160
*225
Weight kg 205 225 300 340 380 380 980 1350 1580 1950 2680 3280
Power 380V 50HZ 5kW max 7.5kW 10kW 14kW 18kW 26kW 40kW 61kW 95kW 145kW 200kW 315kW
