LNEYA CHILLERS
SUNDI (-100 ~ 100℃)
- Temperature Range-100 ~ 100℃
- Temperature Control Accuracy±0.5℃
- Heating Power3.5KW ~ 80KW
- Cooling Capacity AT 0℃3.5KW ~ 80KW
- Circulating Pump Flow and Pressure35~400L/min 2~2.5BAR
- Power Supply12 ~ 200KW
- Place of OriginChina
- Quality Guarantee Period12 months
FEATURES:
Typical Applications Of Cooling Heating Chiller: dynamic constant temperature control of high pressure reactor cold and heat source, dynamic constant temperature control of double-layer glass reactor cold and heat source, dynamic constant temperature control of double-layer reactor cold and heat source, constant temperature of microchannel reactor Control; small thermostat control system, steaming system temperature control, material low temperature high temperature aging test, combined chemical cold source heat source constant temperature control, semiconductor equipment cooling heating, vacuum chamber cooling heating constant temperature control.
Dynamic Temperature Control System Advantages And Functions: temperature range from -120℃ to 350℃, superior performance, high precision, intelligent temperature control. Multi-function alarm system and safety function, 7-inch, 10-inch color TFT touch screen graphic display, magnetic drive pump, no shaft seal leakage problem.
Ultra-high Temperature Cooling Technology Can Directly Cool Down From 300℃ High Temperature. Because only the heat transfer medium in the expansion chamber is in contact with the oxygen in the air (and the temperature of the expansion tank is between normal temperature and 60℃), which can reduce the heat transfer medium. The risk of oxidizing and absorbing moisture from the air. No high-temperature heat medium evaporates at high temperature, and continuous control can be achieved with -80℃ to 190℃, -70℃ to 220℃, -88℃to 170℃, -55℃ to 250℃, and -30℃ to 300℃ without pressurization temperature.
| Model | SUNDI-1035W | SUNDI-1055W | SUNDI-1075W | SUNDI-10A10W | SUNDI-10A15W | SUNDI-10A25W | SUNDI-10A38W | SUNDI-10A60W | SUNDI-10A80W | |
| Temp. range | -100℃～+135℃（the system add pressure 3bar) | |||||||||
| Control Mode | Feedback PID + Our special dynamic control calculation, PLC controller | |||||||||
| Temp. control | Process temp control and jacket temp control model | |||||||||
| Temp. difference | Set or control the temperature difference between jacket oil and raw material process | |||||||||
| Program Editor | 10 programs, each program can edit 40 steps. | |||||||||
| Communication Portocol | MODBUS RTU Protocol,RS485 interface | |||||||||
| Material temp. feedback | PT100 OR 4～20mA or communication（normal: PT100) | |||||||||
| Temp. feedback | The temp. of three points: the inlet and outlet of equipment, reactor material temp.(external temp. sensor) | |||||||||
| Medium temp. acccuracy | ±0.5℃ | |||||||||
| Material temp. accuracy | ±1℃ | |||||||||
| Heating power kW | 3.5 | 5.5 | 7.5 | 10 | 15 | 25 | 38 | 60 | 80 | |
| Cooling capacity kW at | 135℃ | 3.5 | 5.5 | 7.5 | 10 | 15 | 25 | 38 | 60 | 80 |
| 0℃ | 3.5 | 5.5 | 7.5 | 10 | 15 | 25 | 38 | 60 | 80 | |
| -60℃ | 2.8 | 5 | 6.2 | 8 | 9 | 15 | 23 | 38 | 52 | |
| -80℃ | 1.9 | 2.8 | 3.4 | 4.1 | 5 | 8 | 13 | 22 | 30 | |
| -90℃ | 0.7 | 1.2 | 1.6 | 2 | 3 | 4.8 | 7.5 | 12 | 16 | |
| -100℃ | 0.45 | 0.7 | 0.9 | 1.2 | 1.8 | 2.9 | 4.5 | 7.2 | 9.5 | |
| Circulation pump max L/min bar |
35 | 35 | 50 | 60 | 110 | 150 | 200 | 400 | 400 | |
| 2 | 2 | 2 | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | ||
| Pump | Magnetic drive pump | |||||||||
| Compressor | Dorin semi-closed compressor | |||||||||
| Oil separator | EMERSON | |||||||||
| Expansion valve | Electronic expansion valve | |||||||||
| Evaporator | Plate heat exchanger | |||||||||
| Operation Panel | 7-inch touch screen，show temp curve\EXCEL data output | |||||||||
| Safety protection | Self-diagnosis function; freezer overload protection; high pressure switch, overload relay,thermal protection device, liquid low level protection, high temperature protection and temperature fault protection. | |||||||||
| Closed circulation system | The whole system is full closed circulation, there is no oil mist at high temperature and no water vapor at low temperature, pressure do not rise up when system is running. The system will supply oil automatically at low temperature. | |||||||||
| Refrigerant | R404A/R23/R14 | |||||||||
| Connection size | ZG3/4 | ZG3/4 | ZG1 | ZG1 | DN32 PN10 | DN32 PN10 | DN40 PN10 | DN65 PN10 | DN65 PN10 | |
| Water-cooled type W(cooling water@20℃) | 3500L/H 1.5bar~4bar |
5000L/H 1.5bar~4bar |
7000L/H 1.5bar~4bar |
9000L/H 1.5bar~4bar |
12m³/H 1.5bar~4bar |
20m³/H 1.5bar~4bar |
25m³/H 1.5bar~4bar |
40m³/H 1.5bar~4bar |
50m³/H 1.5bar~4bar |
|
| Dimension cm | 80*120*185 | 80*120*185 | 150*100*185 | 150*100*185 | 200*145*205 | 205*145*205 | 250*160*225 | 300*160*225 | 400*160*225 | |
| Weight kg | 435 | 565 | 705 | 890 | 1250 | 1600 | 2100 | 2950 | 3350 | |
| Power 380V 50HZ | 12kW max | 18kW max | 24kW max | 30kW max | 40kW max | 60kW max | 85kW max | 135kW max | 200kW max | |
