SUNDI (-25 ~ 300℃)

SUNDI (-25 ~ 300℃)

  • Temperature Range-25 ~ 300℃
  • Temperature Control Accuracy±0.5℃
  • Heating Power2.5KW ~ 200KW
  • Cooling Capacity AT 20℃2.5KW ~ 200KW
  • Circulating Pump Flow and Pressure20~600L/min 2~2.5BAR
  • Power Supply4 ~ 260KW
  • Place of OriginChina
  • Quality Guarantee Period12 months

Product Details

FEATURES:

Typical Applications Of Cooling Heating Chiller: dynamic constant temperature control of high pressure reactor cold and heat source, dynamic constant temperature control of double-layer glass reactor cold and heat source, dynamic constant temperature control of double-layer reactor cold and heat source, constant temperature of microchannel reactor Control; small thermostat control system, steaming system temperature control, material low temperature high temperature aging test, combined chemical cold source heat source constant temperature control, semiconductor equipment cooling heating, vacuum chamber cooling heating constant temperature control.

Dynamic Temperature Control System Advantages And Functions: temperature range from -120℃ to 350℃, superior performance, high precision, intelligent temperature control. Multi-function alarm system and safety function, 7-inch, 10-inch color TFT touch screen graphic display, magnetic drive pump, no shaft seal leakage problem.

Ultra-high Temperature Cooling Technology Can Directly Cool Down From 300 High Temperature. Because only the heat transfer medium in the expansion chamber is in contact with the oxygen in the air (and the temperature of the expansion tank is between normal temperature and 60℃), which can reduce the heat transfer medium. The risk of oxidizing and absorbing moisture from the air. No high-temperature heat medium evaporates at high temperature, and continuous control can be achieved with -80℃ to 190℃, -70℃ to 220℃, -88℃to 170℃, -55℃ to 250℃, and -30℃ to 300℃ without pressurization temperature.

Model SUNDI
-225V
SUNDI
-225WV
SUNDI
-235V
SUNDI
-235WV
SUNDI
-255V
SUNDI
-255WV
SUNDI
-275V
SUNDI
-275WV
SUNDI
-2A10V
SUNDI
-2A10WV
SUNDI
-2A15V
SUNDI
-2A15WV
SUNDI
-2A25V
SUNDI
-2A25WV
SUNDI
-2A38WV
SUNDI
-2A60WV
SUNDI
-2A95WV
SUNDI
-2A130WV
SUNDI
-2A200WV
Temp. range -25℃~+300℃
Control Mode Feedback PID + Our special dynamic control calculation, PLC controller
Temp. control Process temp. control and jacket temp. control model
Temp. difference Set or control the temperature difference between jacket oil and raw material process
Program Editor 10 programs, each program can edit 40 steps.
Communication
Portocol
MODBUS RTU Protocol, RS485 interface
Material temp.
feedback
PT100 OR 4~20mA or communication(normal: PT100)
Temp. feedback The temp. of three points: the inlet and outlet of equipment, reactor material temp.(external temp. sensor)
Medium temp.
acccuracy
±0.5℃ ±1℃
Material temp.
accuracy
±1℃ ±1.5℃
Heating power kW 2.5 3.5 5.5 7.5 10 15 25 38 60 95 130 200
Cooling
capacity
kW at
300℃ 2.5 3.5 5.5 7.5 10 15 25 38 60 95 130 200
100℃ 2.5 3.5 5.5 7.5 10 15 25 38 60 95 130 200
50℃ 2.5 3.5 5.5 7.5 10 15 25 38 60 95 130 200
20℃ 2.5 3.5 5.5 7.5 10 15 25 38 60 95 130 200
-5℃ 2 3 4.5 6.6 8 12 19 30 46 70 80 125
-20℃ 1 1.8 2.8 3.8 4.6 7 12 16 22 32 43 65
Circulation
pump max
L/min bar
20 35 50 50 60 110 150 150 250 400 400 600
2 2 2 2 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5
Pump LNEYA magnetic drive pump German magnetic drive pump
Compressor Mitsubishi Emerson copeland vortex flexible Dorin seni-closed compressor
Expansion valve Emerson thermal expansion valve/danfoss thermal expansion valve.
Evaporator DANFOSS/KAORI Plate heat exchanger
Operation Panel 7-inch touch screen,show temp curve\EXCEL data output
Safety protection Self-diagnosis function; freezer overload protection; high pressure switch, overload relay,thermal protection device, liquid
low level protection, high temperature protection and temperature fault protection.
Closed circulation
system
The whole system is full closed circulation, there is no oil mist at high temperature and no water vapor at low temperature,
pressure do not rise up when system is running. The system will supply oil automatically at low temperature.
Refrigerant R404A/R507C, optional: R448A
Connection size G1/2 G3/4 G3/4 G1 G1 G1 DN32 DN40 DN40 DN50 DN65 DN65
Water-cooled
type W(@20℃)
600
L/H
800
L/H
1000
L/H
1200
L/H
1600
L/H
2200
L/H
6
m³/H
10
m³/H
14
m³/H
20
m³/H
28
m³/H
36
m³/H
Dimension
(water type)cm
45
*85
*130
45
*85
*130
55
*95
*170
55
*95
*170
70
*100
*175
80
*120
*185
100
*150
*185
/ / / / /
Dimension
(air type)cm
45
*85
*130
45
*85
*130
45
*85
*130
45
*85
*130
55
*95
*170
55
*95
*170
80
*120
*185
100
*150
*185
100
*150
*185
205
*145
*205
245
*145
*205
275
*160
*225
Isolate size
(air type)cm
45
*110
*130
45
*110
*130
55
*120
*170
55
*120
*170
70
*125
*175
80
*145
*185
105
*120
*185
100
*150
*185
100
*150
*185
205
*145
*205
245
*145
*205
275
*160
*225
Positive pressure
(water type)cm
110
*95
*195
110
*95
*195
110
*95
*195
110
*95
*195
110
*95
*195
135
*145
*195
(135+60)
*145
*225
(135+60)
*145
*225
(185+60)
*145
*225
(185+100)
*145
*225
(185+100)
*145
*225
(185+150)
*165
*225
Weight kg 130 180 195 260 320 390 620 820 1100 1350 1680 2250
Power 380V 50HZ 4kW 6kW 8kW 11kW 14kW 21kW 34kW 52kW 79kW 123kW 165kW 260kW
