FEATURES:
The product adopts the international brand compressor Carlyle, which is small in size and high in efficiency. The single compressor can realize the temperature control of -152 °C, and the ultra-low temperature refrigeration technology is at the international advanced level.
1. To save water resources, it is possible to use the glycol-water mixture to carry out circulating refrigeration, strict circulation pipeline design, prevent circulating water pollution, and prolong the use time of circulating water;
2. Original imported compressor, overlapping supercooled refrigeration technology;
3. Double condensation high efficiency system;
4. Computer cascade temperature controller, temperature digital display, adjustment unit 0.1 degree, PT100 temperature sensor, -125°C~ -20°C wide temperature range;
5. Ambient temperature monitoring function to prevent the system operating environment temperature from being too high;
6. It adopts full-closed design, no water absorption during low-temperature operation, ensuring the purity of cold and heat-conductive medium, preventing ice crystals and improving the life of thermal fluid.
APPLITION:
Cryogenic circulators, a very wide refrigeration temperature range, and a controllable temperature of -150 degrees to -5 degrees. It adopts secondary subcooling, fast cooling speed, safe and reliable, and is used for rapid liquid cooling. It is widely used in high-tech industries such as petrochemical, medical, pharmaceutical, biochemical, freeze-drying, pharmaceutical and so on.

Model |
LX-0250N |
LX-0400N |
LX-0700N |
LX-1000N |
LX-1450N |
LX-2000N |
LX-2600N |
LX-3500N |
LX-5000N |
Medium Temperature Range |
-15℃~30℃ |
-25℃~30℃ |
Temp. Control and Dispaly |
ASET multifunctional controller, control outlet temperature of water tank |
Temp. Control Optional |
Temperature feedback PT100 (inlet temperature, outlet temperature) |
Cooling Capacity |
0℃ |
1.5KW |
2.4KW |
4KW |
7.5KW |
10KW |
15.5KW |
20kw |
26.5kw |
38kw |
-10℃ |
1KW |
1.5KW |
2.7KW |
6.3KW |
8KW |
12KW |
15.5kw |
21kw |
30kw |
-20℃ |
|
0.8KW |
1.5KW |
3.5KW |
5KW |
7.3KW |
10kw |
13.5kw |
20kw |
Circulation Pump Flow Rate, Pressure (max) |
20L/min |
20L/min |
35L/min |
35L/min |
75L/min |
75L/min |
110L/min |
200L/min |
250L/min |
1.5BAR |
1.5BAR |
1.5BAR |
1.5BAR |
2.5BAR |
2.5BAR |
2.5BAR |
2.5BAR |
2.5BAR |
Capacity of Liquid Storage |
15L |
17L |
25L |
30L |
40L |
60L |
80L |
150L |
300L |
Compressor |
Tecumseh |
Emerson Copeland |
Evaporator |
Plate Heat Exchanger |
Operation Panel |
7-inch color touch screen shows setting temperature and measuring temperature, temperature curve record, data export excel-format |
Safety Protection |
Self-diagnosis function; freezer overload protection; high pressure switch;overload relay, thermal protection device etc. security protection function. |
Refrigerant |
R-404A |
Connection Size |
G1/2 |
G3/4 |
G1 |
G1 1/4 |
DN40 PN10 |
Product size(cm) |
45*65*120 |
45*65*120 |
55*95*175 |
55*95*175 |
70*100*175 |
70*100*175 |
80*120*185 |
95*170*205 |
100*200*220 |
Weight (air-cooled) |
115KG |
145kg |
180kg |
225kg |
290kg |
340kg |
400kg |
650kg |
950kg |
Power (max ) 50hz |
AC220V 1.5kW |
AC220V 2.2kW |
AC220V 3kW |
AC380V 4kW |
AC380V 5kW |
AC380V 6kW |
AC380V 8 kW |
AC380V 12kW |
AC380V 17kW |
Shell Material |
Cold rolled steel painting |
Optional |
SUS304 Material |
Optional Power |
220V 60HZ three-phases,460V 60HZ three-phases |
